Chirag Aluminium stands out as a top-notch manufacturer and supplier located in Chennai, India, focusing on high-quality aluminium products that meet strict industrial standards. One of their standout offerings is the Aluminium 6061 Forgings, known for their remarkable strength, toughness, and versatility. These forgings are crafted using cutting-edge forging techniques and rigorous quality control, available in a variety of sizes and tempers to cater to different applications. With a strong commitment to precision, durability, and timely delivery, Chirag Aluminium has become a go-to choice in sectors like aerospace, automotive, marine, and general engineering, both in India and around the globe.
Aluminium 6061 Forgings are made primarily from an aluminium alloy that includes magnesium (0.8%–1.2%) and silicon (0.4%–0.8%), along with small amounts of chromium and copper. This alloy boasts impressive mechanical properties, with tensile strength ranging from 240 MPa to 310 MPa and elongation between 8% and 17%, depending on the temper (T6, T651). Renowned for its corrosion resistance, high strength-to-weight ratio, and excellent machinability, Aluminium 6061 is perfect for forging applications that demand durability and structural integrity under pressure. Plus, it’s heat-treatable, which means its mechanical properties can be further enhanced.
Standards : ASTM B247, B247
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Mn | Si | Cr | Cu | Fe | Zn | Al | Mg | Ti | Other Each/Total |
| 0.15 | 0.4-0.8 | 0.15-0.35 | 0.15-0.4 | 0.7 | 0.25 | Remainder | 0.8-1.2 | 0.15 | 0.005/0.15 |
| Tensile Strengtd (PSI) | Yield Strengtd (PSI) | Shear Strengtd (PSI) | Elongation in 2″ | Brinell Hardness |
| 45,000 | 40,000 | 31,000 | 12 | 95 |
Chirag Aluminiun based in Chennai, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 6061 Forgings to meet specific project needs. Our team at Chirag Aluminiun is committed to providing customized solutions for all your requirements. For more details, contact us at sales@chiragaluminium.co.in
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96061 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 | AA6061 | 3.3211 |
Industries that need strong, lightweight, and corrosion-resistant components extensively use Aluminium 6061 Forgings. In aerospace, they’re utilized for aircraft fittings, structural parts, and hydraulic components. The automotive sector incorporates these forgings in chassis, suspension parts, and engine components to cut down on weight and boost performance. In marine applications, they’re essential for shipbuilding hardware and offshore equipment due to their outstanding corrosion resistance. Additionally, these forgings meet general engineering needs, including machinery parts, sports equipment, and precision tools. With their strength, toughness, and versatility, Aluminium 6061 Forgings are a dependable choice for high-performance applications.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
